Source-linked model
Renogy Lycan 5000 Runtime Calculator
Use this source-linked record to estimate runtime from tracked capacity, output, charging, and weight fields. Unknown specs stay unknown until an official or manufacturer-grade source confirms them.
Capacity4800 Wh
AC output3,500 W
Surge7,000 W
ChemistryLiFePO4
ConfidenceEstimated
Source regionglobal/general
Checked2026-07-10
Swipe table sideways
| Battery capacity | 4800 Wh |
|---|---|
| Battery chemistry | LiFePO4 |
| AC output | 3,500 W |
| Surge output | 7,000 W |
| DC output | unknown |
| USB-C output | unknown |
| Solar input | 4,400 W |
| Weight | 120 kg |
| Confidence | Estimated |
| Lifecycle status | Unknown |
| Source region | global/general |
| Last verified | 2026-07-10 |
Solar input uses the official 4400W maximum. DC and USB-C output ceilings remain unknown because the checked official sources do not publish them.
Runtime Starting Points
These are formula estimates using the tracked capacity, a 10% reserve, and each scenario's default wattage and duty cycle. They are planning starters, not measured runtimes.
Swipe table sideways
| Scenario | Default load | Estimate | Scenario confidence | Station page |
|---|---|---|---|---|
| Full-size refrigerator | 500 W at 33% | 22h 15m | Estimated | Use calculator |
| CPAP without heated humidifier | 40 W at 100% | 3d 19h | Estimated | Use calculator |
| Starlink Mini | 32 W at 100% | 5d 1h | Estimated | Use calculator |
| Wi-Fi router | 12 W at 100% | 13d 4h | Estimated | Use calculator |
| LED TV | 100 W at 100% | 1d 12h | Estimated | Use calculator |
Calculator for this station
Adjust watts, duty cycle, reserve, output path, and startup surge with Renogy Lycan 5000 prefilled from the source-linked specs above.
Loading calculatorPreparing calculator
This tool didn't load
Something blocked the calculator from starting. Check your connection or reload the page to try again.
Power station model
Battery capacity (Wh): 4800 WhContinuous output rating (W): 3500 WSurge output rating (W): 7000 W
Estimated runtime2d 13h1d 14h – 3d 4hEstimated runtime: 2d 13h, 1d 14h – 3d 4h
Output path
Estimated runtime
2d 13hEstimated runtime: 2d 13hThis setup has comfortable headroom for overnight use, assuming the wattage estimate is realistic.
Conservative1d 14h
Estimated2d 13h
Optimistic3d 4h
Conservative assumes harder conditions; optimistic assumes favorable conditions.
- This is an estimate. Real runtime changes with load, temperature, battery age, AC/DC output, and device behavior.
- Usable energy
- 3672 Wh
- Average load
- 60 W
- Fixed station overhead
- Unknown (not included)
- Running watts
- 60 W
- Max surge
- n/a
Show your work
Rated Wh is reduced by efficiency, reserve, battery health, and temperature before it is divided by average load.
- Rated battery
- 4800 Wh
- Battery capacity (Wh): 4800 Wh
- Usable energy
- 3672 Wh
- 4800 Wh x 85% x 90% x 100% x 100%
- Average load
- 60 W
- 60 W running, 60 W average after duty cycle and quantity
- Fixed station overhead
- Unknown (not included)
- 60 W / 85% = 70.6 W battery draw; fixed overhead is unknown and excluded
- Estimated runtime
- 2d 13h
- 3672 Wh / 60 W = 2d 13h
- 4800 Wh nominal battery capacity
- AC inverter output path
- 85% conversion efficiency
- 10% reserve kept unused
- 60 W average load from 1 load
- 100% battery health
- 0% temperature loss
- Fixed station overhead unknown; not included
This link contains the numeric values you entered, but not custom load names.
Source-Backed Next Steps
Smallest matching record (8h)Jackery Explorer 600 v2
WattRunTime.com
WattRunTime estimate
Estimated runtime
2d 13hThis setup has comfortable headroom for overnight use, assuming the wattage estimate is realistic.Usable energy3672 Wh
Average load60 W
Fixed station overheadUnknown (not included)
Running watts60 W
Max surgen/a
Runtime range
Conservative1d 14h
Estimated2d 13h
Optimistic3d 4h
Show your work
Rated Wh is reduced by efficiency, reserve, battery health, and temperature before it is divided by average load.
Rated battery4800 WhBattery capacity (Wh): 4800 Wh
Usable energy3672 Wh4800 Wh x 85% x 90% x 100% x 100%
Average load60 W60 W running, 60 W average after duty cycle and quantity
Fixed station overheadUnknown (not included)60 W / 85% = 70.6 W battery draw; fixed overhead is unknown and excluded
Estimated runtime2d 13h3672 Wh / 60 W = 2d 13h
Assumptions
- 4800 Wh nominal battery capacity
- AC inverter output path
- 85% conversion efficiency
- 10% reserve kept unused
- 60 W average load from 1 load
- 100% battery health
- 0% temperature loss
- Fixed station overhead unknown; not included
Warnings
- This is an estimate. Real runtime changes with load, temperature, battery age, AC/DC output, and device behavior.
Share URL
Good fit when
- Capacity is in a larger outage/RV class, so the useful question is usually output limits, recharge speed, and weight rather than watt-hours alone.
- Tracked AC output is high enough for many household plug-in loads, but surge still needs a separate check.
- Tracked solar input is 4,400 W before panel, weather, angle, and controller losses.
Watch out for
- Surge output is tracked, but device startup behavior should still be checked against the actual load.
- Still unknown in the source-backed record: dc output, usb-c output.
- Tracked weight is in a heavier class; plan where it will live before treating it as a grab-and-go station.
- Confidence is not marked verified; keep the linked source context visible before making a purchase or emergency plan.
Related Renogy Records
Nearby source-linked models from the same brand help you compare capacity, output, and unknown fields without leaving the data set.
Phoenix 500
495 Wh, 800 W AC output, confidence: Verified.
Phoenix 300
337 Wh, 300 W AC output, confidence: Estimated.
Phoenix 200
222 Wh, 200 W AC output, confidence: Estimated.
Sources
- Renogy Lycan 5000 solar input FAQ (official; checked 2026-07-10)
- Renogy Lycan 5000 product page (official; checked 2026-07-10)
